Task 7: Wheels to MEB assembly

Assembly time

30 minutes

Tools needed

• 5mm hex-head key

‍

‍

Step 1: Wheels to frame

Prepare:

• 4x Task 1 assembly
• Task 6 assembly
• 8x m5x10 torx screws
• 5mm hex-head key

‍

Step 2: Wheel cable routing

Prepare:

• Step 1 assembly

‍

Step 3: Securing the cables

Prepare:

• Step 2 assembly
• pack of small zip-ties
• pack of big zip-ties

‍

Step 4: Connecting the wheels

Prepare:

• Step 3 assembly

‍

‍

‍
